Pulse Valve Controller AC220V Dust Collector

Pulse Online Deashing Controller AC220V Output For Cleaning Dust Control Device 8 lines

QHK-8A Input voltage is AC220V, output voltage is AC220V

Online deashing controller is the main equipment of the bag type dust collector cleaning system .

The special voltage could be customized.

Its output signal directly controls the pulse jet valve . Made by high technology , it is of high quality and has Long service life .

The item adopts intelligent microprocessor circuit design so it is flexible control , stable performance , operation visually and convenient , without any operation to adjust the potentiometer .

It also adopts the latest anti - jamming design , ensure the system stability , more reliable .

Quick Detail :

1) Body Material : engineering plastic

2) Weight : 1.0 kg

3) Working medium : Air

4) Output Pulse Width adjustment range : 50ms-2500ms

5) Temperature range : -25°c- +60°c

6) Rated output current : 1A

7) Size : 160*160*90mm

8) No violent vibration or shock

9) Rated input voltage : AC220V
10) Rated output voltage : AC220V DC24 optional

Specification :

1. Output Pulse Width adjustment range : 30ms-2500ms
2. Color : transparent
3. Small Operating force
4. Body Material : engineering plastic

5. Rated input voltage : AC220V
6. Rated output voltage :AC220V
7. Long service life
8. Transposition clearly
9. Easy to install

10. Simple operation
