CONSTRUCTION
Body: Aluminium
Core tube: Stainless steel
Core and plugnut: Stainless steel
Core spring: Stainless steel
Sealings & disc: NBR (nitrile / buna-n)
Diaphragm: TPE (hytrel)
Shading coil: Copper
Coil insulation class: F
Connector: Spade plug (cable Φ 6 - 10 mm)
Connector specification: ISO 4400
Electrical safety: IEC 335
Differential pressure (PS): 0,35 - 8,5 bar [1 bar = 100kPa]
Ambient temperature range: -20 to +85°C
8. INSTALLATION
1. The valves can be mounted in any position without affecting operation
2. Pipe connection identifier is: G = G (ISO 228/1) or compression fitting
3. For compression fitting types tightness is achieved by the compressed gasket on the blow tube
4. The use of the rubber gaskets as sealing members will allow a slight misalignment in piping when using compression fittings
5. Other pipe threads are available on request
6. Installation/maintenance instructions are included with each valve
7. Spare Parts Kit and replacement coils are available
 |
